Hahn & Sohn Diesel Generator HDE60SS3-DR (Stage V) Euro 5

The diesel generator Hahn & Sohn HDE60SS3-DR (Stage 5) is a robust three-phase power source designed for demanding industrial and commercial applications. It is equipped with a powerful RAYWIN 4D36TIG01/5 engine — a four-cylinder, turbocharged, liquid-cooled unit — compliant with the strict EU Stage V emission standard.

• The generator delivers a rated power output of 50 kW (65 kVA) and a maximum output of 55 kW (70 kVA). The automatic voltage regulator (AVR) ensures a stable power supply, protecting connected equipment from voltage fluctuations and enabling reliable operation of sensitive devices.
• The Ultra Silent soundproof housing maintains a noise level of only 53 dB(A) at 7 m, an exceptionally low value for this performance class. The advanced ComAp InteliLite 4 AMF25 control panel provides full monitoring and control of all operating parameters.
• This model is ideal for industrial facilities, construction sites, logistics centers, telecommunication bases, and commercial buildings, where high reliability, performance, and compliance with environmental standards are required.

Key Features

• Rated power: 50 kW (65 kVA)

• Maximum power: 55 kW (70 kVA)

• Engine: RAYWIN 4D36TIG01/5, Stage 5 – 4-cylinder, turbocharged, water-cooled

• Three-phase output: 400/230 V, 50 Hz

• Automatic voltage regulator (AVR) – stable voltage output, suitable for sensitive equipment

• Low noise level: 53 dB(A) @ 7 m – Ultra Silent enclosure

• Fuel consumption: approx. 5.9 l/h at 50% load

• Fuel tank: 105 L – extended runtime without refueling

• Control unit: ComAp InteliLite 4 AMF25

• Robust construction for continuous operation

Notice: Product image is for illustration purposes only. The actual product design may vary slightly.

Note: The unit is delivered ready for use – with oil and coolant filled, charged batteries, and tested. Before first startup, it is recommended to read the manual and check fluid levels and overall condition.
